Mixing capacity:
90 l/min
Maximum grain size:
16 mm
Connection value:
400 V, 3 Ph, 50 Hz, 7.5 kW
Control voltage: 42 V
Drive motor:
7.5 kW, 254 rpm
Mixing tube:
Rubber mixing tube
Pedestal:
Static
Wheels:
2 rollers
Water connection:
Geka DN19 (3/4") – 2.5 bar working pressure
Operation and control:
Start/Stop
Auto-stop time control
Filling height:
1,175 mm
Hopper volume:
110 litres ~ 3.5 sacks (at 30 kg)
Outlet height:
620 mm
Length/Width/Height:
2,545/770/1,175 mm
Total weight:
255 kg
Water flow meter:
150 – 1,500 l/h
Dosing shaft:
90 l/min
Pressure booster pump:
Not included
Connection cable:
Not included
Water hose/air hose:
Not included
Silo/container handover:
Possible through delivery hood
